The edge blu is thin and lightweight, measuring just 0.5” thick and weighing less than 9 ounces. edge blu has an incredibly wide viewing angle, 5.5” LCD and a sensitive capacitive touch keypad. edge blu is simple to configure, calibrate, measure, log and transfer data to a computer or a USB drive. This meter features Hanna’s exclusive CAL Check™ to warn if the HALO pH electrode being used is not clean or if your buffers are contaminated during calibration. An Indicator is also displayed after calibration showing the overall probe condition that is based on the offset and slope characteristic of the pH electrode.
The versatile design of edge blu makes equally at home in your hand, on a lab bench, or mounted on a wall.
Each edgeblu is supplied with a HI11102 HALO™ Bluetooth pH
electrode. The Halo uses Bluetooth Smart Technology (Bluetooth 4.0),
which is energy efficient and allows the probe to operate on 1 CR2032
battery for approximately 500 hours. The HI11102 HALO pH electrode is a
double junction, gel filled, glass body pH electrode with a built-in
thermistor temperature sensor. All readings are automatically
compensated for temperature variations.
The HI11102 HALO pH electrode transmits measurement data directly to edgeblu
or a compatible Apple or Android device. All HALO pH electrodes are
auto-detected providing pH sensor type, calibration data and serial
number when connected. The HALO pH electrode also features a blue LED
ring that changes flashing frequency based on whether it is in discovery
mode or when it is connected to the edgeblu or compatible
device. The button located on the HALO™ pH probe is used to place it in
discovery mode or to log data directly to the edgeblu or compatible Apple or Android device.
Wireless Bluetooth pH Electrode - edge blu uses HALO™ Bluetooth pH electrodes with a built-in temperature sensor to send measurement data wirelessly to the meter or a compatible Apple or Android device running the Hanna Lab App.
Advanced pH Electrode Diagnostics - edge blu features advanced pH electrode diagnostics to ensure worry free measurements. Diagnostics include Hanna’s exclusive CAL Check feature that alerts users to potential problems during calibration.
Capacitive Touch - edge blu features a capacitive touch keypad that gives a distinctive, modern look. The keypad is sensitive enough to be used with laboratory gloves and has a fast response. Since the keypad is part of the screen, there are no buttons buttons to get clogged with sample residue.
Cradle and Electrode Holder - edge is equipped with a benchtop cradle with an adjustable swivel electrode holder to charge and hold the edge securely in place at the optimum viewing angle.
Wall Mount - Using the wall mount cradle (included), edge can be placed on a wall, leaving zero footprint on the benchtop space. The cradle has a built-in connector to power edge and charge its batteries. edge's zero footprint is designed to save you valuable benchtop space.
Large, Easy to Read LCD - edge blu features an LCD that measures 5.5” and is clearly viewable from over 5 meters. Add to that a wide viewing angle of 150 degrees and you have one of the clearest LCDs in the industry. In addition to its large LCD, edge also features full text guides displayed on the bottom of the screen. There is no need to decipher scrambled abbreviations.
Capacitive Touch - edge blu features sensitive capacitive touch buttons for accurate keystrokes when navigating edge’s menus and screens. Since they are part of the screen, the buttons can never get clogged with sample residue.
Bluetooth Digital pH Electrodes - edge blu uses HALO Bluetooth digital pH electrodes. Once a probe is connected, all sensor information including sensor operating specifications and calibration information is transferred. pH electrodes are easy to exchange when you want to change from measuring with one type to another without the need for recalibration.
Up to Five-Point pH Calibration - In standard mode, edgeblu can be calibrated automatic up to 5 points with 7 standard buffers (1.68, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45) and 2 custom buffers.
Good Laboratory Practice (GLP) feature - The GLP data can be review at anytime at a push of a button. GLP data includes, date, time, buffers, offset and slope of the last pH calibration.
CAL Check pH Electrode Monitoring Technology - Hanna’s exclusive CAL Check feature analyzes the pH electrode response in the pH buffers during the calibration process to alert the user of potential problems such as contaminated buffer and clean electrode. After calibration, indicators for probe condition is displayed on the measurement screen. The probe condition is based on offset and slope characteristics of the pH electrode.
What's in the Box:
(1) HI2202 edge® blu includes benchtop docking station with electrode holder
(1) Wall mount cradle
(1) USB cable
(1) HI11102 glass body
(1) Gel filled pH electrode with temperature sensor
(1) pH 4 buffer solution sachets
(1) pH 7 buffer solution sachets
(1) pH 10 buffer solution sachets
(1) Electrode cleaning solution sachets
(1) 5 VDC power adapter
(1) Instruction manual
(1) Instrument quality certificate
